Description

INYO # 4600-3106 PENTAIR # 273106 GENERAL DESCRIPTION: THIS IS THE SHAFT WITH SPACERS ON THE PENTAIR 26-1165 PUSH PULL VALVE THIS IS A SINGLE BLACK PLASTIC MOLDED PIECE, AND INCLUDES ONLY THE SHAFT AND 2 SPACERS. THE HANDLE AND TOP CAP ARE NOT INCLUDED WITH THIS ITEM SEE 4600-3241 FOR THE COMPLETE ASSEMBLY GENERAL INFO MATERIAL: SHAFT: BLACK PLASTIC SPACERS: BLACK PLASTIC TOP CAP: WHITE PLASTIC (NOT INCLUDED WITH THIS ITEM) HANDLE: BLACK PLASTIC (NOT INCLUDED WITH THIS ITEM) DIMENSIONS: LENGTH: 16-3/8″ (INCLUDING HANDLE) LENGTH: 13″ (A) (WITHOUT HANDLE) SHAFT DIAMETER: 9/16″ (B) (AT THE HANDLE END,TAPERS DOWN TO 7/16″ AT THE OTHER END SPACERS: TOTAL # 2 SPACERS INCLUDED DIAMETER: 1-15/16″ THICKNESS: 15/32″ FROM OUTSIDE TO OUTSIDE GROOVE: 5/16″ SPACING: (MEASURED ON CENTERLINE FROM FIRST SPACER WITH THE FIRST SPACER AT ZERO) 1ST 0 2ND 7-1/2″ SPACER O-RINGS: (NOT INCLUDED WITH THIS ITEM) THESE ARE STRETCHED ON TO THE SPACERS SO THE DIMENSIONS SHOWN ARE FOR THE ORIGINAL O-RINGS BEFORE THEY ARE STRETCHED OUTSIDE DIAMETER: 1-7/8″ INSIDE DIAMETER: 1-1/2″ HOLES IN SHAFT: (MEASURED ON CENTERLINE FROM THE HANDLE END OF THE SHAFT) HOLE: 3/16″ AT 5/16″ FROM END INCLUDES: SHAFT WITH 2 SPACERS (ALL ONE SINGLE MOLDED PIECE) MARKINGS: “PISTON ASSEMBLY 27-3241” MOLDED ONTO THE SHAFT

*******************************************************************************

TOP PLATE INFO INCLUDED? NOT INCLUDED INYO # 4600-3077 PENTAIR # 273077 GENERAL DESCRIPTION: THIS IS THE TOP PLATE IN THE 26-1165 PENTAIR PUSH PULL VALVE MATERIAL: WHITE PLASTIC SHAPE: THIS IS ROUND WITH A SLOT IN THE TOP. DIMENSIONS: DIAMETER: 2-3/8″ (A) TOTAL HEIGHT: 15/16″ (B) CENTER HOLE DIAMETER: 9/16″ INCLUDES: TOP PLATE ONLY MARKINGS: “OPEN” AND “LOCK” WITH ARROWS MOLDED ON TOP

*******************************************************************************

HANDLE INFO INCLUDED? NOT INCLUDED INYO # 4600-3089 PENTAIR # 273089 GENERAL DESCRIPTION: THIS IS THE HANDLE ON THE PENTAIR 26-1165 PUSH PULL VALVE MATERIAL: BLACK PLASTIC SHAPE: T STYLE, WITH COTTER PIN HOLE IN THE SIDE DIMENSIONS: LENGTH: 3″ (A) WIDTH: 3/4″ HEIGHT: 3-1/4″ (B) INCLUDES: HANDLE ONLY MARKINGS: NO MARKINGS

*******************************************************************************
