Description

This motor is more robust and faster as it generates 5 HP of output power! Turning the electrical energy to mechanical power is now quick and easy with this motor. It’s made with endurance and sturdiness to meet all your requirements!

Product Features:

Two speed rigid base pool pump motor

Comes with four thru bolts on a 5.812 bolt circle

Contains open drip-proof technology

Additional Features:

Output HP: 4 Hp

Current: 12.0 A

Frequency: 60 Hz

Service Factor: 1

Duty: continuous

Frame size: P56Y

Protector: thermally protected

UL: recognized

Output KW: 3.0 kW

Voltage: 230 V

Speed: 3450 rpm

Ambient temperature: 50°C

Phase: 1

Insulation Class: F

Enclosure: drip proof

CSA: Y

Electrical type: permanent split capacitor, single or dual voltage

Rotation: counterclockwise pump end

Motor orientation: horizontal

Opp drive end bearing: BALL

Shaft type: threaded

Poles: 2/4

Mounting: thru bolt

Drive end bearing: BALL

Dimensions:

Frame length: 8″

Shaft extension: 2.37″

Overall length: 12.62″

Shaft diameter: 0.50″

Material(s): stainless steel

Frame material: rolled steel

Weight
22.00 LBS
